• ON/OFF control and dimming of individual or grouped luminaires
• Selection of PWM output frequency by ETS, from 250 Hz to 6 kHz
• Parallel connection of outputs possible to increase output power
• Fade on/off time, minimum and maximum brightness level, linear or logarithmic dimming curve settable via ETS
• Soft or instantaneous switching on and off, with settable delay
• Configuration of behaviour after power reset, bus ON/OFF, unloading via ETS
• Channels can be set by ETS as independent, parallel or with copy function from another channel
• Blocking function, forced operation, staircase light, scenes, night, counter and logic functions for each channel, settable from ETS
• Alarm for power failure
• Manual control with membrane buttons for local ON/OFF testing of channels 1-2-3-4: in manual mode, short press of a channel button activates/deactivates the load, pressing for at least 2 seconds causes the load to flash every 1 s approx.
• Relay contact for switching off the AC/DC power supply when 12/24/48 Vdc outputs are switched off, or alternatively as relay for auxiliary output
• Auxiliary output function via relay with status indication via KNX

Environmental conditions and other features

• Operating temperature: -20 °C ... + 40 °C
• Storage temperature: -40 °C ... + 60 °C
• Transport temperature: -40 °C ... + 60 °C
• Max. nominal enclosure temperature (tc): 80 °C
• Relative humidity: 91% non-condensing
• Degree of protection: IP00 (IP20 in junction box or switchboard)
• Power supply and load wiring: 0.2 to 4.0 mm2 (24 to 11 AWG) for single cable / 0.2 to 6 mm2 (24 to 9 AWG) for stranded cable
• KNX bus wiring: 0.6 to 0.8 mm2 (19 to 18 AWG)
• Stripping: 8.0 mm
• Plastic housing
• Switchgear for panel mounting on 4 UM DIN rail
• Weight: 200 g
• Dimensions (WxHxD): 71 x 91 x 62 mm
